Fixed Fire Monitor YAPS30-50
- Product No.:2024111165640
Fixed Fire Monitor YAP30-50 Water monitors use water as the medium to extinguish fires from a distance. This type of monitor is suitable for use in petrochemical plants, storage tank areas, aircraft hangars, warehouses, ports, and other locations, and is an ideal choice for fire trucks. A fire monitor consists of a base, water inlet pipe, rotating body, water inlet / collection pipe, jet adjustment ring, handle, and locking mechanism, among other components. The barrel can rotate horizontally and vertically and can be locked in place. The monitor has a wide range of operating pressures, a long range, and can adjust between straight stream and water mist spray. Its light weight, compact size, full functionality, and effectiveness in fire extinguishing are particularly notable features.
Fixed Fire Monitor YAPS30-50 Features
1.Aluminum alloy gun body, aluminum alloy gun head
2.Stainless steel double handle design
3.The pitch adopts the brake belt design, which is reliable and effective
4.Nozzle flow 30-40-50 adjustable, DC spray adjustable
5.Double-bearing rotating mechanism, excellent stability and durability, especially suitable for frequent use
6.Optional manual drain valve, open after use without removing residual moisture
Fixed Fire Monitor YAPS30-50Technical data
1.Made of light aluminum alloy / red finish as above pictures
2. Flow is 30-40-50L/S
3.Shooting distance: ≥65m
4.Vertical angle of 80º up and -30º down
5.Horizontal angle:360º
6.Inlet: DN100 Flange
